51.2V 300AH/400AH/500AH/600AH/700AH/800AH Rack Mounted Lithium Battery Pack, Life04 battery. Household use.
Payment :
30% by T/T in advanceShipping Port :
Shanghai or NingboLead Time :
10-15 working days after paymentsAdvantages:
High performance traction* LiFePO4 100Ah lithium battery replaces a 200Ah
lead battery
Safest lithium (LiFePO4)technology
Long service life
High discharge current
Light weight
Low automatic discharge
| Model |
PNGER51300-LV |
PNGER51400-LV | PNGER51500-LV |
PNGER51600-LV |
PNGER51700-LV |
PNGER51800-LV |
| Cell Type | EVE-LFP prismatic battery cell-3.2V100Ah |
|||||
| Nominal Voltage | 51.2V (Single) |
|||||
| Nominal Capacity | 300AH | 400AH |
500AH |
600AH |
700AH |
800AH |
|
Nominal Energy |
15.36KWH |
20.48KWH |
25.6KWH |
30.72KWH | 35.84KWH | 40.96KWH |
|
Nominal Range |
40~58.4V |
|||||
| System parameters | ||||||
|
Weight(battery /control Box/) |
126kg |
168kg |
210kg |
252kg |
294kg |
336kg |
| Size (L*W*H) | 482*464*396mm |
482*464*528mm |
482*464*660mm |
482*464*792mm |
482*464*942mm |
482*464*1056mm |
|
Protection class |
IP54 (indoor) |
|||||
| Cooling mode |
Free cooling |
|||||
|
Depty of discharge (DOD) |
≥90% |
|||||
| Ambient temp. |
Charge:0℃~55°℃/Discharge:-20℃~60℃/ Storage:-10℃~45℃ |
|||||
| Installation |
Stackable |
|||||
| Cycle life |
≥6000times |
|||||
| Warranty |
5+5years |
|||||
| Communication |
CAN, RS485 |
|||||
| Certificates |
UN38.3\MSDS\CE |
|||||
FAQ:
1: Can the product be shipped to my area?
We export to most countries/regions (Centre/ South America, EMEA, SEA, SSA, AU). We will check and confirm for you after you provide the region.
2: How can I make payment?
100% T/T or maximum we can accept 30% T/T in advance and 70% T/T upon goods ready before shipment.
