PNG 365W-380W 166mm Double Glass Bifacial Mono PERC Solar Module

PNG 365W-380W 166mm Double Glass Bifacial Mono PERC Solar Module

166mm 120cells monocrystalline perc half-cell solar modules, Bifacial solar module. They are widely used in residential , floating system and etc

  • Payment :

    30% by T/T in advance
  • Shipping Port :

    Shanghai or Ningbo
  • Lead Time :

    10-15 working days after payment

Advantages:

Utilizing the power of the sun has never been more efficient and stylish than with our cutting-edge Bifaicial 380W Solar Panels. Designed with precision and engineered to perfection, these panels redefine the standards of solar energy generation.

Electrical Specifications
Module Type

PNG120M-

365DGB

PNG120M-

370DGB

PNG120M-

375DGB

PNG120M-

380DGB

Testing Condition STC  NOCT STC  NOCT STC  NOCT STC  NOCT
Max. Power (Pmax/W) 365 273 370 276 375 280 380 284
Voltage at Max. Power (Vmp/V) 34.2 31.8 34.4 32 34.6 32.2 35.5 32.3
Current at Max. Power (Imp/A) 10.68 8.56 10.76 8.63 10.84 8.69 11 8.82
Open circuit voltage (Voc/V) 40.7 38.2 40.9 38.3 41.1 38.5 41.5 38.7
Short circuit current (Isc/A) 11.43 9.25 11.52 9.32 11.6 9.38 11.69 9.45
Module Efficiency(%) 20.00% 20.31% 20.59% 20.89%
solar panel PNG    solar power energy
Standard Test Condition (STC):Irradiance 1000W/m², Cell Temperature 25℃, AM1.5
Nominal Module Operating Temperature (NOCT):Irradiance 800W/m², Ambient Temperature 20℃, AM1.5, Wind Speed 1m/s
Mechanical Specifications
Cell Type 9BB MONO 166x83mm
No.of Cells 120(6x20)
Dimension 1755x1038x35mm
Weight 24.0kg
Glass 3.2mm,Low Iron Tempered Glass
Frame Anodized Aluminium Alloy
Junction Box IP68,3 diodes
Output Cables 4m㎡,Length 300mm or customized
Connector type MC4 compatible

Temperature Characteristics
NOCT Temperature 44C±2℃
Temperature Coefficient(Pmax) -0.36%/C
Temperature Coefficient(Voc) -0.28%/C
Temperature Coefficient(Isc) 0.05%/C



Maximum Ratings
Maximum system voltage(IEC) 1500V DC
Snow/Wind 5400Pa/2400Pa
Operating Temperature -40C~+85℃
Maximum series fuse rating 20A



Packaging Configuration
Per Pallet 31 pcs
Per 40'HQ Container 806 pcs



FAQ:

1.How could I get a sample?

Before we received the first order, please afford the sample cost and express fee. We will return the sample cost back to you within your first order.



2.Sample time?

Existing items: within 15 days.



3.Whether you could make our brand on your products?

Yes. We can print your Logo on both the products and the packages if you can meet our MOQ.
